138 ASC110 / ASC130 / ASC150
3.6. Individual Operations of Maintenance
Every 20 Hours or Daily Every 20 Hours or Daily
3.6.3. Checking oil in the hydraulic tank
• Place the roller onto flat, firm surface and stop the
engine.
• Check the oil level. (oil gauge).
• Refill oil using filling device by means of filling quick
coupling according to chapter 3.6.29.
! NOTE !
If the oil level falls below the lower edge of the
”MIN” oil-level indicator, the engine will automati-
cally stop and signal lamp (27) will light up.
NOTE
In case of more extensive losses find the location of
hydraulic system leaks and repair the cause.
By stopping the engine in case of oil leakage, the hydrau-
lic system of the machine is protected and operation is
environment-friendly, since in case of hydraulic hose
damage not all the content of the hydraulic tank but only
limited amount would leak out. The engine can only be
started after refilling oil.
