19ASC 130
SPECIFICATION MANUAL
ASC 130 HD ASC 130 HDPD
ASC 130 HT ASC 130 HTPD
Operation weight with cab EN500-1 kg (lb) 13635 (30059) 13735 (30280)
Operation weight EN500-1
to drum kg (lb) 8135 (17934) 8235 (18155)
to axle kg (lb) 5500 (12125) 5500 (12125)
Static linear load kg/cm (lb/in) 37.0 (207) (-)
Operation weight EN500-1 with cab
and protective frame ROPS kg (lb) 13865 (30566) 13965 (30787)
to drum kg (lb) 8175 (18022) 8275 (18243)
to axle kg (lb) 5690 (12544) 5690 (12544)
Static linear load kg/cm (lb/in) 37,2 (208) (-)
Operation weight with cab according to ISO 6016 kg (lb) 13805 (30434) 13905 (30654)
to drum kg (lb) 8060 (17769) 8160 (17989)
to axle kg (lb) 5745 (12665) 5745 (12665)
Static linear load kg/cm (lb/in) 36,6 (205) (-)
Operation weight with cab and protective
frame ROPS according to ISO 6016 kg (lb) 14035 (30941) 14135 (31162)
to drum kg (lb) 8100 (17857) 8200 (18078)
to axle kg (lb) 5935 (13084) 5935 (13084)
Static linear load kg/cm (lb/in) 36,8 (206) (-)
Operation weight with cab, protective frame ROPS
and padfoot segments according to ISO 6016 kg (lb) 15715 (34645) (-)
to drum kg (lb) 9780 (21561) (-)
to axle kg (lb) 5935 (13084) (-)
Operating weight according to EN 500 is weight of the machine with full operating liquid, half filling of fuel, water tank
of sprinkling and operator’s weight 75 kg (165 lb).
Operating weight according to ISO 6016 is weight of the machine with maximum operating liquid, of fuel, water tank of
sprinkling and operator’s weight 75 kg (165 lb).
The weights may differ depending on additional modifications of the machine made on special request of the customer
or if additional options and/or accessories are used.
Weights of machine without cabin can be calculated from all the above weights by deducting
Operation weight kg (lb) -220 (485) -220 (485)
to drum kg (lb) -105 (231) -105 (231)
to axle kg (lb) -115 (254) -115 (254)
Static linear load kg/cm (lb/in) -0,48 (2,7) (-)
The weight of the machine with the cover roof is calculated on all models by deducting the weight of the cab and adding
the following weights:
Operation weight kg (lb) +140 (308) +140 (308)
to drum kg (lb) +60 (132) +60 (132)
to axle kg (lb) +80 (176) +80 (176)
Static linear load kg/cm (lb/in) +0,27 (1,5) (-)
For all machine variants, the weight of machine including blade is calculated by adding the weights below:
Operation weight
to drum kg (lb) +1240 (2734) +1240 (2734)
to axle kg (lb) -330 (728) -330 (728)
