57ASC110/ASC130/ASC150/ASC200/ASC250
OPERATING INSTRUCTIONS
1 - Travel control
2 - Transport gear selector
3 - Working gear pre-selector
4 - Parking brake switch
5 - Emergency brake push-button
6 - Vibration switch
7 - Steering wheel
8 - Engine speed selector
9 - Switchbox
10 - Hydraulic oil thermometer
11 - Fuel gauge
12 - Revolution counter
13 - Hourmeter
14 - Engine diagnostics
15 - Engine idling switch
16 - Engine diagnostics switch
17 - Troubleshooting switch
18 - Stop engine - signal lamp
19 - Engine warning - signal lamp
20 - Water in fuel - signal lamp
21 - Maintenance signal lamp
22 - Battery charging - signal lamp
23 - Brake - signal lamp
24 - Idle (neutral) position - signal lamp
25 - Air filter - signal lamp
26 - ASC (Anti Spin Control) - signal lamp
27 - Oil level in hydraulic tank - signal lamp
28 - Vibration on - signal lamp
29 - Clogging of the pressure filter of hydraulic oil - signal lamp
30 - Indicators - signal lamp
31 - Horn push-button
32 - Rear lights - switch + signal lamp
33 - Front lights - switch + signal lamp
34 - Auxiliary lights - switch + signal lamp
35 - Warning lights - switch + signal lamp
36 - Warning beacon - switch + signal lamp
37 - Indicators switch
38 - Drum traction slip control - switch + signal lamp
39 - Heating fan - switch + signal lamp
40 - Vibration pre-selector
41 - ASC connector
42 - Fuse box
