65ASC110/ASC130/ASC150/ASC200/ASC250
OPERATING INSTRUCTIONS
Engine idling switch (15)
Use the switch to turn on engine idling with an engine start.
Signal lamp in the switch will light up upon activating.
Engine diagnostics switch (16)
In case of a malfunction of the engine, clutch the diagnos-
tics switch (16) to identify the defect on the basis of
flashing code on signal lamp (18).
Note
Signal lamp (18) or (19) will go on in case of an engine
malfunction, depending on severity of the defect. After
activating switch (16), the will start flashing the code of the
first defect see chapter 2.7.7.
If both pilot lamps indicating defects (yellow – 19 and red
– 18) go on after pressing the switch when the ignition box
is on that means no defects have been identified by
engine ECM.
Troubleshooting switch (17)
The switch is in the middle position.
Turn it continuously any direction (+ forward
or - backward) to find defects according to
flashing codes of signal lamps (18) or (19).
! NOTE !
Use the switch for trouble shooting only.
