88 ASC110/ASC130/ASC150/ASC200/ASC250
2.7. Controlling and operation of the machine
Selecting driving direction and speed
• Move the travel control (1) from neutral to the required
direction - little movement = low speed and vice versa.
Upon moving the travel control (1), the neutral (24)
signal lamp will go off.
Reversing - move the control (1) to the opposite direction
via neutral.
Note:
Using the selector (8) can be set engine speed between
1800 RPM to max.
! NOTE !
Selector (2) - transport gear - can be activated
when driving on finished surface.
It is possible to activate selector (2) while the
machine is under load; rabbit symbol will light up.
Should towing power be insufficient, turn the
transport gear selector off (2).
Do not drive across (traverse) slopes
with high inclination! Drive directly
up the slope!
Prior to driving down a steep slope,
engage working gear by deactivating
selector (2)!
Deactivate selector (2) while the
machine is stopped or moving in a
low speed! Do not turn selector off at
higher speeds - this will cause rapid
deceleration and impact in the
hydraulic system.
Do not use engine speed selector (8)
to control the machine speed.
If you have to stop the machine in a
slope, first move travel control (1) to
neutral and then press parking brake
button (4).
