3.2. Media specifications
3.2.6. Lube grease
To lubricate the Machine you must use plastic grease containing
lithium according to:
• ISO 6743/9 CCEB 2
• DIN 51 502 KP2K-30
3.2.7. Glass washer uid
The medium used in the glass washer tank will water (up to 0°C
temperature) plus glass washer agent for motor vehicles.
Replace water with antifreeze agent at
the temperatures below 0°C (32°F).
3.2.5. Gearbox oil
To lubricate drum’s gearbox and gearboxes for axle drive
(wheels), please use quality oil corresponding to API GL-5 or EP
or MIL-L-2105 C
Viscosity of SAE 80W/90 for ambient temperature -10 °C ÷
+30°C (14°F ÷ 86°F)
Viscosity of SAE 80W/140 for ambient temperature +20 °C ÷
+45°C (68°F ÷ +113°F)
Operating temperature of oil shall not ex-
ceed 85°C ÷ 90°C (185°F ÷ 194°F).
3.2.8. Air-conditioning lling
0.8 kg of coolant Halocarbon 134a
0.2 l of oil PAG 150
0.005 l of contrast medium
3.2.4. Hydraulic oil
Only the quality hydraulic oil of performance class under ISO
6743/ HV (corresponds to DIN 51524 part 3 HVLP; CETOP RP 91
H) shall be used for the Machine’s hydraulic system.
Fill the Machines normally with hydraulic oil that has cinematic
viscosity of 68 mm
2
/s at 40°C (104°F) ISO VG 68. This oil is most
appropriate for its use within the widest range of ambient tem-
peratures.
Note
Hydraulic system is able to be lled with synthetic oil which, if
any leaks occur, will be degraded with no residues, via the mi-
croorganisms found in water and in soil.
Please consult always with oil manufac-
turer or dealer any switching from min-
eral oil to synthetic one or mixing the oils
of various brands!
