Ammann ASC 70 - Loading the Machine Using a Crane

83ASC70
396098B
1
2
(22 050 lb)
274050
OPERATION MANUAL
Do NOT enter the area under the lifted
load!
Observe the relevant national safety
measures when loading the machine with
a crane.
Upon loading completion, please return
the safety arm to its initial position.
Use corresponding, undamaged riggings
of sucient loading capacity.
To sling, please use only the lifting lugs on
the Machine designed for that purpose.
Only a trained slinger may carry out the
slinging.
2.8.1.2. Loading the machine using a crane
• When loading with crane the Roller is tted with lifting lugs.
• When lifting the Roller the Machine’s joint shall be secured
against turning.
How to secure the joint:
• Fold down the arm (1), lock with safety pin (2)..
