Ammann ASC 70 - 1.3. Specifications

14 ASC 70
ASC 70 Cummins Tier 3
D HX PD HXPD
Weight
Operating weight of EN 500-1+A1 (CECE) with cab,
ROPS
kg (lb) 7140 (15740) 7620 (16800) 7090 (15630) 7570 (16690)
Operating weight of EN 500-1+A1 (CECE) with cab kg (lb) 6990 (15410) 7470 (16470) 6940 (15300) 7420 (16360)
Operating weight of EN 500-1+A1 (CECE) with plat-
form, rail
kg (lb) 6840 (15080) 7320 (16140) 6790 (14970) 7260 (16010)
Operating load of EN 500-1+A1 (CECE) with cab,
ROPS on front axis
kg (lb) 4020 (8860) 4080 (8990) 3970 (8750) 4030 (8880)
Operating load of EN 500-1+A1 (CECE) with cab,
ROPS on rear axis
kg (lb) 3120 (6880) 3540 (7800) 3120 (6880) 3540 (7800)
Weight of half uid capacities kg (lb) 110 (240) 110 (240) 110 (240) 110 (240)
Operating weight of ISO 6016 with cab, ROPS kg (lb) 7250 (15980) 7730 (17040) 7200 (15870) 7680 (16930)
Maximum weight with the cab, ROPS, accessories,
weighing
kg (lb) 9260 (20410) 9740 (21470) 8120 (17900) 8600 (18960)
Maximum permitted weight according to ROPS kg (lb) 13200 (29100) 13200 (29100) 13200 (29100) 13200 (29100)
Static linear load of front drum kg/cm (lb/in) 23,9 (133,8) 24,3 (136,1) - -
Cab weight kg (lb) 220 (490) 220 (490) 220 (490) 220 (490)
Weight of ROPS kg (lb) 210 (460) 210 (460) 210 (460) 210 (460)
Weight of ROPS/FOPS (CNH design) kg (lb) 290 (640) 290 (640) 290 (640) 290 (640)
Weight of sheet roof on ROPS kg (lb) 140 (310) 140 (310) 140 (310) 140 (310)
Weight of canopy kg (lb) 60 (130) 60 (130) 60 (130) 60 (130)
Weight of canopy posts (version without ROPS) kg (lb) 60 (130) 60 (130) 60 (130) 60 (130)
Weight of blade kg (lb) 500 (1100) 500 (1100) 500 (1100) 500 (1100)
Weight of 3 padfoot segments kg (lb) 1090 (2400) 1090 (2400) - -
Weight of tyre lling 0°C kg (lb) 367 (810) 367 (810) 367 (810) 367 (810)
Weight of tyre lling -25°C kg (lb) 420 (930) 420 (930) 420 (930) 420 (930)
Driving characteristics
Number of speeds - 3+1 3+1 3+1 3+1
Maximum transport speed km/h (MPH) 11 (6,8) 8,4 (5,2) 11,1 (6,9) 8,5 (5,3)
Working speed 1 km/h (MPH) 2,5 (1,6) 2,5 (1,6) 2,5 (1,6) 2,5 (1,6)
Working speed 2 km/h (MPH) 3,5 (2,2) 3 (1,9) 3,5 (2,2) 3 (1,9)
Working speed 3 km/h (MPH) 4,7 (2,9) 3,6 (2,2) 4,8 (3) 3,7 (2,3)
Climbing ability % 45 60 45 60
Climbing ability with vibration % 40 40 40 40
Lateral static stability % 48,8 48,8 48,8 48,8
Lateral stability during driving without vibration % 25 25 25 25
Lateral stability during driving with vibration % 15 15 15 15
Maximum gradient when towing machine on slope % 60 60 60 60
Turning radius inner (edge) mm (in) 3090 (121,7) 3090 (121,7) 3090 (121,7) 3090 (121,7)
Turning radius outer (contour) mm (in) 4685 (184,4) 4685 (184,4) 4685 (184,4) 4685 (184,4)
Front approach slope % 65 65 65 65
Rear approach slope % 51 51 51 51
Type of drive - Hydrostatic Hydrostatic Hydrostatic Hydrostatic
Number of driving axles - 2 2 2 2
Oscillation angle ° ±12 ±12 ±12 ±12
Angle of steering ° ±36 ±36 ±36 ±36
1.3. Specifications
