3.6. Lubrication and Maintenance
Every 20 hours of operation (daily)
3.6.1. Engine oil level check
• Shut o the engine and wait ca 5 minutes until oil ows o
into the engine sump.
• Pull out oil dipstick, wipe it, put it back, take it out and check
the level.
• Keep the level within the division lines stamped on the dip-
stick. The bottom L (Low) division line indicates possible oil
level, the upper division line H (High) indicates the highest
level.
• Use ller neck to rell oil.
! CAUTION !
Amount of oil in between the marks on the dipstick
makes 1,5 litres (1.6 U.S Quart).
Replenish oil of the identical type as per par. 3.2.1.
NEVER use engine unless there is correct
oil level in the engine.
