Ammann ASC 70 - 1.1. Basic specification

10 ASC 70
Please ll in the following data:
(see Pin label, Label of the CUMMINS engine)
Type of machine
................................................................................................................
ICV/PIN (Serial number of the machine)
................................................................................................................
Production year
................................................................................................................
Type of engine
................................................................................................................
Serial number of the engine
................................................................................................................
1.1. Basic specification
Machine description
Single drum roller with an articulated frame with afront smooth
or padfoot steel driven vibrating drum and driven rear axle with
two treaded tyres. Steering using the articulated frame.
Machine application
The ASC 70 rollers are suitable for medium and small-sized com-
paction works in transport construction (construction of roads,
railways, cart roads, and forest roads) and building construction
(industrial zones, embankments), etc.
ASC 70 D roller with asmooth drum is suitable for the compac-
tion of all kinds of soils. It is possible to be used for the compac-
tion of clay soils up to alayer thickness (after compaction) of
15cm (5,9 in), loam soils up to alayer thickness of 25 cm (9,8in),
mixed soils up to alayer thickness of 35 cm (13,8 in), sandy and
gravel materials up to alayer thickness of 45 cm (17,7 in). The
roller can also be used for compaction by means of stabilisation.
ASC 70 PD roller with apadfoot drum (synchronous kneading
and vibrating eect) is suitable for the compaction of clay soils
up to alayer thickness (after compaction) of 20 cm (7,9 in), loam
soils up to alayer thickness of 25 cm (9,8 in), and mixed soils up
to alayer thickness of 35 cm (13,8 in).
The roller ASC 70 HX for continuous use in severe conditions
requiring the continuous application of a high tractive power,
or for continuous compaction on a slope above 30% – smooth
drum.
The roller ASC 70 HXPD for continuous use in severe conditions
requiring the continuous application of a high tractive power,
or for continuous compaction on a slope above 30% – padfoot
drum.
ASC 70 PDB roller with apadfoot drum and blade for spread-
ing materials. The blade is the optional equipment supplied per
order.
The machines are intended for operation in conditions of the
following types according to ČSN IEC 721-2-1 (038900): WT, WDr,
MWDr (i.e. mild, warm dry, hot dry with alimited temperature
range of from -15 °C (5 °F) to +45 °C (113 °F).
The standard type of the machine is not intended for road traf-
c. For more information, please contact your dealer.
Please refer to the data in the table below always when ap-
proaching the dealer or the manufacturer.
