Ammann ASC 70 - Blade

76 ASC70
396094
III
I
0
II
396073
III
I
0
II
369074
396075
2.7. Machine control and use
2.7.7. Blade
• Unlock the blade on both sides. Unlocked blade
• Control function is given by four positions:
0 position basic position
Position I blade going down
Position II blade ascending
Position III blade is in oating positions
• Drop the blade to the ground via shifting the actuator to “III”
position (oating position)
or via the pedal.
