15ASC 70
SPECIFICATION MANUAL
ASC 70 Cummins Tier 3
D HX PD HXPD
Steering
Type of steering - Joint Joint Joint Joint
Steering control - Hydraulic Hydraulic Hydraulic Hydraulic
Linear hydraulic motors - 2 2 2 2
Engine
Manufacturer - Cummins Cummins Cummins Cummins
Type - QSB3.3-C99 QSB3.3-C99 QSB3.3-C99 QSB3.3-C99
Power according to ISO 3046-1 kW (HP) 74 (99) 74 (99) 74 (99) 74 (99)
Number of cylinders - 4 4 4 4
Cylinder capacity cm³ (cu in) 3300 (201) 3300 (201) 3300 (201) 3300 (201)
Nominal speed min¯¹ (RPM) 2200 2200 2200 2200
Maximum torque Nm/rpm 412/1600 412/1600 412/1600 412/1600
Average fuel consumption
l/h
(galUS/h)
8,8 (2,3) 8,8 (2,3) 8,8 (2,3) 8,8 (2,3)
Engines complies with emission regulations -
EU Stage IIIA,
U.S. EPA Tier 3
EU Stage IIIA,
U.S. EPA Tier 3
EU Stage IIIA,
U.S. EPA Tier 3
EU Stage IIIA,
U.S. EPA Tier 3
Cooling system of engine - Liquid Liquid Liquid Liquid
Axle
Maximum tyre pressure MPa (PSI) 0,15 (21,8) 0,15 (21,8) 0,15 (21,8) 0,15 (21,8)
Pattern of tyres - UK 5 Diamond UK 5 Diamond TD-02 Tractor TD-02 Tractor
Number of tyres - 2 2 2 2
Number of rear wheels - 2 2 2 2
Size of tyres - 14,9x24´´ 14,9x24´´ 14,9x24´´ 14,9x24´´
Type of tyres - Tubeless Tubeless Tubeless Tubeless
Number of pads (only PD version) - - - 104 104
Pad contact surface (only PD version)
cm² (sq in) - - 114 (17,7) 114 (17,7)
Pad height (only PD version) mm (in) - - 80 (3,1) 80 (3,1)
Brakes
Operating - Hydrostatic Hydrostatic Hydrostatic Hydrostatic
Parking -
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Emergency -
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Vibration
Frequency I Hz (VPM) 30 (1800) 30 (1800) 30 (1800) 30 (1800)
Frequency II Hz (VPM) 41 (2460) 41 (2460) 41 (2460) 41 (2460)
Amplitude I mm (in) 1,7 (0,067) 1,7 (0,067) 1,7 (0,067) 1,7 (0,067)
Amplitude II mm (in) 0,86 (0,034) 0,86 (0,034) 0,86 (0,034) 0,86 (0,034)
Centrifugal force I kN 145 145 145 145
Centrifugal force II kN 130 130 130 130
Type of drive - Hydrostatic Hydrostatic Hydrostatic Hydrostatic
