Ammann ASC 70 - Page 52

48 ASC70
100
220
180
250
J1939
°C
396051B
2.6. Actuators and dashboard instruments
Vibration preselector - 2 positions
High frequency - low amplitude
Low frequency - high amplitude
2476
Before the machine starts moving, use the switch to set the re-
quired amplitude. Before changing the amplitude, rst stop the
machine, use the switch to change the amplitude and then start
moving the machine again.
2854
596191
Warning lights
Limitation for drum slip
It is used only for Roller to move onto the loading area of a trans-
port vehicle.
Note
If the Roller is equipped with the drum slip limitation system
then ATC will not be used.
! CAUTION !
Transport speed controller must be switched OFF
when drum slip limitation is enabled. At the same
time the vibration is interlocked.
It is forbidden to vibrate on the spot!
It is forbidden to change the vibration
amplitude while driving.
