4.13 Slave CPU
The Slave CPU (BRD86SCPU) provides the interfacing signals and I/O’s required to allow the FACP
to connect / communicate to a variety of termination boards.
A single chip micro controller U7 controls all operations of the FACP Slave CPU. This device contains
the control program within Read Only Memory (ROM).
Automatic Termination Board Sensing
A unique feature of the Slave CPU is its ability to automatically sense the type of board it is connected
to without the user having to configure the board to suit.
