7.8 Tools
Pressing  allows for the Testing of the following selected fields
TOOLS MENU
0:ALARM 1:FAULT 2:LAMP
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 45: The TOOLS menu
Pressing  brings up a further detailed selection sub-menu for an Alarm tests.
ALARM TEST
0:ZONE 1:DEVICE
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 46: The ALARMS test menu
Pressing  brings up a further detailed selection sub-menu for a Fault tests.
FAULT TEST
0:ZONE 1:DEVICE
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 47: The FAULT test menu
Pressing  initiates a LAMP Test. Which will scroll thru and illuminate all LED’s and LCD screen
