Ampac FireFinder PLUS - Input Programming; Output Programming; Zone Programming Setup

Page 51
4. Set / Edits and enables / disables the day/night settings then. Press
5. Allocates / Edits the Loop and Devices Groups.
After scrolling through the groups a prompt tells the operator to press to confirm the
changes.
8.9.3 Input
Press  INPUT:
By following the screen prompts as above Edit or Delete an INPUT in a panel or a loop.
Screen: PROGRAM MENU SELECTING AN INPUT
 IN A PANEL
 ON A LOOP
I/O MODULE
LOOP
Select I/O MODULE NO. then
Select LOOP NO. then
INPUT
DEVICE
Select I/P NO then
Select DEVICE NO. then
EDIT / DELETE DESC
INPUT
Select INPUT NO. then button
ALPHA BUTTONS ARE ACTIVE
EDIT Lx Sx I/Px DESC STRING DESC
8.9.4 Output
Press  OUTPUT:
By following the screen prompts as above Add, Edit or Delete an output in a panel or on a loop.
8.9.5 Panel Based MCP
Press  to EDIT
8.9.6 Sub Address
Press  to EDIT
8.9.7 Zone programming
Press  to EDIT.
Key in the zone number and select the key.
Enter or change the description ( DESCR ) by pressing buttons to move the flashing underline or
curser. Press the numeric buttons multiple times to access characters.
