Page 33
7 The Main Menu
The MAIN MENU is accessed by pressing
MAIN MENU
0:ALARMS 1:STAGE 1 ALARMS 2:PRE-ALARMS
3:FAULTS 4:DISABLES 5:WALK TESTS
6:STATUS 7:TOOLS 8:SETUP
9:ABOUT
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Numbering System:
denotes the menu structure number
denotes the sub-menu numbering
denotes a sub-menu within a sub-
menu
denotes another sub-menu within a
sub-menu
Figure 22: The Main Menu (No Network)
Pressing the appropriate number on the keypad while in the MAIN MENU the user can view any;
7.1 Alarms
Pressing Displays all Alarms present on the system.
ZONE: 1
Zone 1
STATUS: ALARM
‘DATE’ ‘TIME’
ZONE ALARM 1 OF 1
DEVICE>
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 23: The ALARMS display
Pressing the will display the Device Information the screen, pressing the will return
it to Zone Information
7.2 Stage 1 Alarms
Pressing Displays all Stage 1 Alarms present on the system
ZONE: 1
Zone 1
STATUS: STAGE 1 ALARM
‘DATE’ ‘TIME’
ZONE STAGE 1 ALARM 1 OF 1
DEVICE>
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 24: The STAGE 1 ALARMS display
Pressing the will display the Device Information on the screen, pressing the will
return it to Zone Information
