Page 53
8.9.8 Extra Devices Detected
The FireFinder PLUS LCD will indicate extra devices have been detected by displaying the screen
below and the FAULT LED will be illuminated.
FIREFINDER 26/2/2007 08:05:45
EXTRA DEVICES DETECTED
GOTO PROGRAMMING MENU TO RESOLVE
SYSTEM IS NOT NORMAL
AC:3Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 74: Resolving Extra Modules and Devices
To resolve select FUNCTION, enter PASSWORD, press  and the screen below will appear
PROGRAMMING MENU
0: RESOLVE EXTRA MODULES AND DEVICES
1: ON SITE PROGRAMMING
SELECT NO.
AC:3Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 75: Added Module or Device
Select  (Selecting  presents the PROGRAMMING MENU) then  or  (as seen below) then
ENTER to ADD the module or device to the configuration, or skip to resolve the changes manually in
the Programming Menu.
0: ADD EXTRA MODULES 1: ADD EXTRA DEVICES
2: DEVICE TYPE MISMATCH 3: MODE MISMATCH
SELECT NO.
AC:3Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 76: Resolving Extra Modules or Devices
8.9.9 Mismatch Detected
If a mismatch is detected the Normal Default Screen will change to that shown below. Go to the
Programming Menu and select either  Resolve Extra Modules and Devices then 
(Device Type) or  (Mode) to resolve the mismatch, OR On Site Programming to resolve manually.
Loop 1 Sensor 1
L1 S6 Z1 STAT: TYPE MISMATCH
ZONE FAULTS 1 of 1
Figure 77: Resolving a Mismatch
Self Learn is enabled / disabled in the EEPROM programming. If enabled FireFinder PLUS has the
ability to detect extra or missing modules or devices, (that is devices or modules that have been added
or removed) or there has been a change of the type of module or device.
Note: If a change does occur the FACP will take 30seconds to register the event on the LCD and
illuminate the FAULT LED.
