Figure 68: Zone Configuration Latching / Non-latching
Use or to change the setting
Configuration settings are Latching, Non-Latching, AVF, Self Reset ( 0 to 99 seconds ). After setting
the Configuration the ZONE I/O GROUPS are programmed.
Figure 69: Zone I/O Groups
After scrolling through the groups and entering what I/O GROUPS will be turned on by what module/s
or device/s in a zone/s the operator is prompted to press to confirm the entries and / or
changes.
8.9.2 Device
Press DEVICE:
Use these buttons to EDIT and move through wording & numbering
Use these buttons to MOVE between fields i.e.: DESC & TYPE and next
parameter
Enter the and number then scroll through the following screens.
Press or Press
To EDIT or to DELETE
1. EDIT LxSx DESCRIPTION AND TYPE STRING. Edit then. Press
e.g.: DESC Loop 1 Sensor 1
TYPE SMOKE
2. Allocate / Edit the Device to a Zone and set the device type then. Press
e.g.: XP95 Photo, XP95 Heat etc-
3. Set /Edit and display the Output Configurations or options then. Press
e.g.: Latching, AVF, Non-latching etc
To Next Page
