2 Introduction
2.1 System Overview
The purpose of the FireFinder PLUS Fire Alarm Control Panel (FACP) is to monitor changes in
inputs, report those changes and update selected outputs as programmed.
2.2 Key Features
The FireFinder PLUS panel is capable of supporting:
➢ Apollo Discovery and XP95 Intelligent Detectors, Multisensor, Photoelectric, Ionisation,
Thermal (heat) and CO detectors.
➢ Conventional two wire zone detector circuits
➢ Multiple input/outputs
➢ Agent Release
➢ Fan Control
➢ High Level Interfaces
➢ SmartGraphics
➢ EV3000 – Early Warning System
➢ Nurse Call
➢ SmartTerminal
➢ Remote LED mimics
➢ Peer to Peer networking
➢ Master Slave (Main - Sub) networking
➢ Main panel plus Data Gathering Panels networking
Figure 1: Typical Application
