Configuring Communication
34
NXD-500i 5" Modero Wall/Flush Mount Touch Panel with Intercom
Both HTTP and HTTPS Ports are enabled by default via the Manage System > Server page.
If the Master has been previously configured for secured communication, click OK to accept the AMX SSL
certificate (if SSL is enabled) and then enter a valid username and password into the fields within the Login
dialog.
4. Click OK to enter the information and proceed to the Master’s Manage WebControl Connections window.
5. The Manage WebControl Connections page (FIG. 30) is accessed by clicking on the Manage connections link
within the Web Control section in the Navigation frame. Once activated, this page displays links to G4 panels
running the latest G4 Web Control feature previously setup and activated on the panel.
FIG. 30 Manage WebControl Connections page (populated with compatible panels)
Compression Options
Compatible devices field
showing G4 WebControl links
G4 panels
To Next Page
