Photo 2.7.3
Laser Pointing Straight
We will be using a Gauge block that has a line going down the side. You can use any tool as long as it has a
straight line reference. We want the laser to be pointing perfectly straight.
We drew a line on the block to use as a guide point. I will check the laser at the far left making sure its
leveled to my guide point, and move the block all the way across too see where the laser ends up at. The
laser should be in the exact position. The image below shows you its not straight on the left the laser is
directly on my guide line and on the right the laser is above my guide line meaning the laser is slightly
pointed up. See photo 2.7.4
