Analog way Pulse 2 - 5.1.5 Rear Panel Pulse²-H - Ref. PLS350-H

29
1.  100-240 VAC 2.5A 50/60HZ / FUSE F4A 250 VAC; internal, autoswitchable; 110W
2. 3G/HD/SD-SDI: SDI #1 to #2
3. S/PDIF: audio inputs #1 to #2
4.  for audio inputs (balanced) #1 to #4
5.  for audio outputs (balanced) #1 to #2
6. S/PDIF: audio outputs #1 to #2
7. 
8. HDMI inputs #1 and #2 / HDMI #1 and HDMI #2
9.  HDBaseT inputs #1 and #2
10. DVI  DVI-D inputs #3 and #4. Capability to receive digital audio signal from HDMI connector
via an adaptator (HDMI-compable)
inputs #3 and #4
 connector for HDBaseT LAN
 connector for remote control LAN
 HDBaseT outputs #1 and #2
 HDMI outputs #1 and #2
 communicaon port with D89 female connector
17.  HDBaseT 5-pin MCO connectors output #1 and #2 for InfraRed and Serial
HDBaseT communicaon signals
5.1.5 Rear panel Pulse
2
- H - Ref. PLS350-H
1
10 118 9
15
17
12 13 14
5.1.5 Rear panel Pulse
2
-H - Ref. PLS350-H
2 3 4 5
6 7
16
