Analog way Pulse 2 User Manual

30

2
-H - Ref. PLS350-H
1 2 3 4 5 6
119
10
8
7
1.  4-line VFD
2. 
 -  un-scaled layer for sll frames
-  un-scaled, posionable layer for sll logos
- Layer A/B: scaled posionable layers for live sources
4.  -  access source 1 to 4, select frame/logo 1 to 4
- HDMI 1/2: access HDMI 1 or HDMI 2, select frame/logo 5 to 6
-  access SDI 1 to SDI 2, select frame/logo 7 to 8
5. Layer: - Black: clear the layer
-freeze/unfreeze the input selected in the currently selected layer
6.  select the output #1 or #2, a layer and a source, then press TAKE
 allows to quickly display a foreground Frame
8. : hold for 3 seconds for stand-by mode
9.  Home menu or back one level - Enter: validate the menu or command
  shortcut to transion menu
- Preset: recall a custom stored preset
- Split Screen: load a split screen preset
- Swap: exchange sources between layer A and layer B
11. TAKE: transion the pre-selected sources onto the Program output with the selected eects
5.1.2 Front panel Pulse
2
-H- Ref. PLS350-H
