Spectrum Analyzer 2-34 Measure Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 2-81
C/I Signal Type Menu
Key Sequence: Shift > Measure (4) key > Masks and C/I > C/I > Carrier Signal Type
After you select a signal type, by pressing a submenu key, the “C/I Menu”
on page 2-80 is automatically displayed. This is the default behavior even if
you press the active key (with the red circle displayed).
NB FHSS: Press this submenu key to set Narrowband Frequency Hopping
Spread Spectrum as the interfering signal type.
WB FHSS: Press this submenu key to set Wideband Frequency Hopping
Spread Spectrum as the interfering signal type.
Broadband: Press this submenu key to set Broadband (such as CDMA or
GSM) as the interfering signal type.
Back: Returns to the “C/I Menu” on page 2-80. without changing the
currently-selected signal type.
Figure 2-67. C/I Signal Type Menu
NB FHSS
Broadband
WB FHSS
C/I Signal Type
Back
