Interference Analyzer (Option 25) 3-15 Measurements Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 3-41
3-15 Measurements Menu
Key Sequence: Measurements
Note The red circle on the submenu key indicates the currently active setting.
Spectrum: Pressing the Spectrum submenu key sets the instrument to a
traditional spectrum analyzer display. When Spectrum is active, pressing the
Spectrum submenu key opens a menu for Spectrum Analyzer
measurements. See the “[Spectrum] Measure Menu” on page 3-42.
Spectrogram: Pressing the Spectrogram submenu key sets the instrument
to display a spectrogram. When Spectrogram is active, pressing the
Spectrogram submenu key opens the “Spectrogram Menu” on page 3-62.
Signal Strength: Pressing the Signal Strength submenu key sets the
instrument to display signal strength. When Signal Strength is active,
pressing the Signal Strength submenu key opens the “Signal Strength Menu”
on page 3-63.
RSSI: Pressing the RSSI submenu key sets the instrument to display RSSI
(Received Signal Strength Indicator). When RSSI is active, pressing the RSSI
submenu key opens the “RSSI Menu” on page 3-64.
Signal ID: Pressing the Signal ID submenu key opens the “Signal ID Menu”
on page 3-65.
Interference Mapping: Pressing the Interference Mapping submenu key
opens the “Interference Mapping Menu” on page 3-66.
Figure 3-34. IA Measurement Menu
Measurements
Spectrum
Spectrogram
Signal Strength
RSSI
Signal ID
Interference
Mapping
