3-15 Measurements Menu Interference Analyzer (Option 25)
3-42 PN: 10580-00349 Rev. H Spectrum Analyzer MG
[Spectrum] Measure Menu
Key Sequence: Measurements > Spectrum
For a shortcut to the active measurement or this main menu if no measurement is active,
press the touch screen where the words IA (Spectrum) are located, in the upper right corner of
the display.
Power and Bandwidth: Opens the “Power and BW Menu” on page 3-43.
Masks and C/I: Opens the “Masks and C/I Menu” on page 3-50.
AM/FM Demod: Opens the “AM/FM Demod 1/2 Menu” on page 3-54.
Generator: Opens the “Generator Menu (Optional)” on page 3-57. This
submenu key is present only in spectrum analyzers with a Tracking
Generator option.
IQ Waveform Capture: Opens the “IQ Waveform Capture Menu
(Option 24)” on page 3-58. This submenu key is present only when
Option 24 is installed.
Coverage Mapping: Opens the “Coverage Mapping Menu (Option 431)”
on page 3-61. This submenu key is present only when Option 431 is
installed.
All Measurements Off: Turns off all measurements.
Figure 3-35. IA Spectrum Measure Menu
Masks and
C/I
IQ Waveform
Capture
Measure
All Measurements Off
Power and
Bandwidth
Coverage
Mapping
AM/FM
Demod
Generator
