3-12 Marker Menu Chapter 3 —Mobile WiMAX Signal Analyzer
3-30 PN: 10580-00236 Rev. D WiMAX MG
3-12 Marker Menu
This feature is available only when the Power vs Time measurement is activated from the
RF Meas menu (Measurements > RF > Power vs. Time).
These instruments have 6 regular line markers and 6 delta markers. Marker information
includes time and power level in dBm. Delta marker information includes delta time and
delta power.
Key Sequence: Marker
3-13 Sweep Menu
Key Sequence: Shift > Sweep (3) key
Marker
123456:Press this submenu key to select and set up a marker for
display
On Off: Press this submenu key to turn On and Off the selected
(underlined) marker in the Marker submenu key face
Delta
On Off: Press this submenu key to turn a delta marker On or Off. You
can move the delta marker to read offsets in time and power by using the
rotary knob or by entering a time offset using the number keypad.
Gated Power
On Off: Press this submenu key to turn Gated Power On and Off.
All Markers Off: Press this submenu key to turn Off all markers and
remove them from the display
Figure 3-27. Mobile WiMAX Marker Menu
Sweep Single/Continuous: This submenu key toggles between
continuous sweep and single sweep. In single sweep mode, the results of a
sweep are displayed on the screen while the instrument awaits a trigger
event to start a new sweep.
Trigger Sweep: Pressing this submenu key causes the instrument to make
a single sweep when the instrument is in single sweep mode. This key has
no function when the instrument is in continuous sweep mode.
Figure 3-28. Mobile WiMAX Sweep Menu
Marker
Marker
1 2 3 4 5 6
On
Off
Gated Power
On Off
Delta
On Off
All
Markers
Off
Sweep
Sweep
Continuous Single
Trigger
Sweep
