Tracking Generator MG PN: 10580-00339 Rev. C 2-1
Chapter 2 — E-Series Tracking
Generator
(Option 20)
2-1 Generator Mode
Option 20 adds a Tracking Generator to the Spectrum Analyzer mode of the instrument. The
Tracking Generator generates a swept signal with an output frequency that is the same as
the tuning frequency of the spectrum analyzer.
Additionally, a CW generator feature is included in Option 20. The sine wave output
frequency and power is set by the user. Refer to Section 2-5 “CW Generator Overview”
on page 2-8.
The output power is leveled and has a specified power range –50 dBm to +0 dBm in
0.1 dB steps.
Power output information is available for both absolute and transmission (normalized)
measurements.
Enhanced power level calibration is available for the generator output. Additional
information about the enhanced level calibration is provided later in this chapter.
2-2 Tracking Generator Overview
1. Set the Mode to Spectrum Analyzer. Refer to Chapter 1 for details.
2. Preset the instrument (Shift+1 > Preset).
3. Set the spectrum analyzer frequency range using the Frequency (Freq) menu and
submenus. Refer to the Spectrum Analyzer Measurement Guide (10580-00244) for
additional information.
4. Press the Shift key, then the Measure (4) key. Press the Generator key.
5. Press the Output Power button and set the output power (at the output connector before
any external attenuation). In tracking mode, the output is leveled and flat over the
spectrum analyzer frequency range.
6. Set the Generator Mode to Tracking. In Tracking Mode, the output frequency is paired
with the spectrum analyzer input sweeping frequency.
7. Turn Generator Output On. The output power turns on at the level that has been set
previously with the Output Power key.
Note
Operation outside this power range is possible. However, performance and
compliance with specifications are not guaranteed.
