Spectrogram Menu
Key Sequence: Measurements > Spectrogram
Sweep Interval: Press the Sweep Interval submenu key and use the rotary
knob or keypad to set the time from 0 seconds to 60 seconds.
Record: When the Time Span is set to an interval other than Auto, the
spectrogram plots will be automatically saved when the waterfall display is
full by pressing the Record submenu key.
Recording Time: When Record is set to On, the Recording Time submenu
key is displayed. Press this submenu key to specify how long the instrument
will record the spectrogram to mass memory before stopping. If there is
insufficient mass memory in the current location (Internal or USB), the
Sweep Interval will be adjusted if currently set as Auto. If the Sweep Interval
setting is not Auto, the maximum recording time will be limited to what will fit
into the currently selected location.
Time Cursor: The Time Cursor is used to view the spectrum at any spot in
the spectrogram display. Press the Time Cursor submenu key to turn on the
horizontal time cursor. Use the up or down arrow key to move the cursor
vertically through the spectrogram. The date and time that the measurement
at the cursor position was taken is displayed at the top of the screen.
Reset/Restart Measurement: Pressing this key will clear the captured
spectrogram display and start a new series of measurements.
Back: Returns to the “Measurements Menu” on page 3-41.
Figure 3-56. IA Spectrogram Menu
