Interference Analyzer (Option 25) 3-15 Measurements Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 3-63
Signal Strength Menu
Key Sequence: Measurements > Signal Strength
Auto Scale: Press the Auto Scale submenu key to automatically scale
the display range.
Max Level: Set the desired maximum display range value by pressing
the Max Level submenu key.
Min Level: Set the desired minimum display range value by pressing the
Min Level submenu key.
Speaker On/Off: Press the Speaker On/Off submenu key to turn on the
audio output.
Volume: Press the Volume submenu key to set the speaker or
headphone volume to a comfortable level. Use the up or down arrow
keys to adjust the volume.
Field Strength: This measurement allows the use of an antenna with
known gain characteristics and measures the field strength over the
frequency range of the antenna in units of dBm/m
2
, dBV/m, dBmV/m,
dBµV/m, Volt/m, Watts/m
2
, dBW/m
2
, A/m, dBA/m, or Watt/cm
2
.
On/Off: Turns field strength measurements on or off.
Antenna: This submenu key displays a list box that lists all the
antennas for which the instrument has data, including both
standard antennas and custom antennas that have been added by
using Master Software Tools. Use the up or down arrow keys or
the rotary knob to select the desired antenna and press Enter.
Back: Returns to the Signal Strength menu.
Back: Returns to the “Measurements Menu” on page 3-41.
Figure 3-57. IA Signal Strength Menu
