Interference Analyzer (Option 25) 3-4 Spectrogram
Spectrum Analyzer MG PN: 10580-00349 Rev. H 3-3
and time that the measurement at the cursor position was taken is displayed at the top
of the screen.
9. Press the Marker main menu key to place up to six markers on the signal and display
the power and frequency at each marker position.
Note
When the Time Cursor is activated and is not on the zero trace position, the
instrument will automatically stop making measurements.
Note
Screen captured images are provided as examples. The image and measurement
details shown on your instrument may differ from the examples in this
Measurement Guide.
Figure 3-1. Interference Analyzer Spectrogram
