Anritsu Spectrum Master MS2720T User Manual

Interference Analyzer (Option 25) 3-15 Measurements Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 3-67
Bearing Lines Menu
Key Sequence: Measurements > Interference Mapping > Bearing Lines
Save Current Bearing Location & Direction: Records a bearing line on
the display, starting from the instrument’s current location, based on GPS.
This performs the same function as the trigger on the Anritsu MA2700A
Handheld Interference Hunter.
Delete Last Saved Bearing: Press this button to delete the last bearing line
from memory. The bearing line will also be removed from the map. This may
be repeated to delete more than one measurement.
Delete All Saved Bearings: Press this button to remove all of the bearing
lines from the screen and memory.
Back: Returns to the “Interference Mapping Menu” on page 3-66.
Figure 3-61. IA Bearing Lines Menu
Bearing Lines
Back
Delete
Last
Saved Bearing
Delete
ALL
Saved Bearings
Save Current
Bearing
Location & Direction
