3-13 Marker Menu
Key Sequence: Marker
Press the Marker main menu key to open the Marker menu. The instrument is equipped with
six markers. Any or all markers can be employed simultaneously.
3-14 Sweep Menu
Key Sequence: Shift > Sweep (3) key
Marker: Selects the active marker (1 to 6). The underlined marker number
is the active marker. Each press of the submenu key moves the underline to
the next marker number. Pressing Shift causes reverses the direction of
marker selection. Press the Shift button again to change back to the original
direction.
On/Off: Turns the selected marker underlined in the Marker submenu key
On or Off.
Marker Table On/Off: Causes a table to be displayed below the sweep
window. The table is automatically sized to display all markers that are
turned on. In addition to the marker frequency and amplitude, the table also
shows delta frequencies and amplitude deltas for all markers that have
deltas entered for them.
All Markers Off: Turns off all markers.
Figure 3-34. W-CDMA/HSPA+ Marker Menu
Sweep Single/Continuous: This submenu key toggles between
continuous sweep and single sweep. In single sweep mode, the results of a
sweep are displayed on the screen while the instrument awaits a trigger
event to start a new sweep.
Trigger Sweep: Pressing this submenu key causes the instrument to make
a single sweep when the instrument is in single sweep mode. This key has
no function when the instrument is in continuous sweep mode.
Figure 3-35. W-CDMA/HSPA+ Sweep Menu
Marker Table
On Off
Marker
On
Off
All
Markers
OFF
Marker
1 2 3 4 5 6
Sweep
Trigger
Sweep
Sweep
Continuous Single
