6-12 Measurements Menu TD-LTE Signal Analyzer
6-38 PN: 10580-00234 Rev. T 3GPP MG
Power vs. Resource Block Menu
Key Sequence: Measurements > Modulation > Power vs. Resource Block
Autoscale Color Map: Adjusts the RB Max Value and Range automatically
on the color map.
RB Color Map Max Value: Press to adjust the RB Color Map Max Value
manually.
RB Color Map Range: Press to adjust the RB Color Range manually.
Back: Press this submenu key to return to the “Modulation Menu” on
page 6-37.
Figure 6-32. TD-LTE Power vs. Resource Block Menu
Back
Power vs RB
Autoscale Color Map
RB Color Map
Max Value
0.0 dBm
RB Color Map
Range
100 dB
