3-14 Measurements Menu EVDO Signal Analyzer
3-30 PN: 10580-00235 Rev. D 3GPP2 MG
CDP MAC Menu
Key Sequence: Measurements > Demodulator > CDP MAC
CDP Data Menu
Key Sequence: Measurements > Demodulator > CDP Data
Zoom: Press this submenu key to select one of these three settings to view
16, 32, or 64 carriers in the measurement display.
Zoom Start: Press this submenu key, then enter the required zoom start
index. For example, to start at code 2, which is the second code power that
is displayed, press the 2 key on the numeric keypad, then press either the
submenu Enter key (which appears when the numeric keypad is used) or the
Enter key.
In addition, press this key, then use the Arrow Keys or rotary knob to
change the zoom start index. The CDP submenu key remains after pressing
the rotary knob or the Enter key.
CDP Units: Press this submenu key to toggle between Relative units (in dB)
or Absolute units in (dBm). Select Relative to show CDP power values in dB
relative to Pilot and MAC Power, or Absolute to show power values in dBm.
Back: Returns to the “Demodulator Menu” on page 3-28.
Figure 3-25. EVDO CDP Menu
CDP Units: Press this submenu key to toggle between Relative units (in dB)
or Absolute units in (dBm). Select Relative to show CDP power values in dB
relative to Pilot and MAC Power, or Absolute to show power values in dBm.
Back: Returns to the “Demodulator Menu” on page 3-28.
Figure 3-26. EVDO CDP Data Menu
CDP MAC
CDP Units
Relative Absolute
Back
Zoom Start
0
Zoom
16 32 64
CDP Data
CDP Units
Relative Absolute
Back
