3. For models prior to 1987, unscrew SJ cord retainer to expose heating element wires.
For models after 1987, remove top or center access plate. Unsnap hinge pin from
female socket and remove, or unplug hinge pin lead wires to remove hinge pin. If
heated glass is used, cut Black and White lead wires to glass. Remove heating element
from door.
4. Using a square-head or clutch-head driver, remove screws on both side rails only.
Remove top and bottom door rails first.
5. Drive rails from glass, using mallet and block, always starting at corner of door.
6. Once rails have been removed from glass, re-insert new friction-fit glazing channel on
new glass and drive rails onto glass.
