ANthony 101 - Electrical Information for Model 2100 Low Temp Doors, Frames & ELS Electronic Lighting System Heater Amperages @ 120 Volts

Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 88 of 95
MODEL 101 NORMAL TEMPERATURE
(2-PANE HEATED GLASS – CASE TEMP 31°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
415
731
1046
1361
1677
24 x 67
658
1174
1691
2208
2724
24 x 75
736
1313
1889
2466
3043
26 x 67
682
1223
1764
2305
2846
26 x 75
763
1367
1970
2574
3177
28 x 75
790
1421
2051
2682
3312
28 x 79
814
1467
2121
2775
3429
30 x 36
458
816
1174
1532
1890
30 x 67
731
1321
1910
2500
3090
30 x 75
817
1475
2132
2790
3447
30 x 79
842
1524
2206
2888
3570
NOTE: Add 10-20% to above values depending on door opening frequency.
80. Electrical Information for Model 2100 Low Temp Doors,
Frames & “ELS” Electronic Lighting System
Heater Amperages @ 120 Volts
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE:
Low temp doors with heaters, 3-Pane Heated Reflective Glass (5.75 W/SQ. FT.)
APPLICATION:
Case Temperature -10°F, Humidity 74% or less, @ 75°F ambient.
24 x 36
1.11
2.19
3.24
4.23
5.29
6.48
7.47
8.46
9.52
10.58
24 x 67
1.84
3.37
4.94
6.54
8.14
9.88
11.48
13.08
14.68
16.28
24 x 75
1.98
3.65
5.38
7.18
8.95
10.76
12.56
14.36
16.13
17.90
26 x 67
1.97
3.71
5.40
7.17
8.86
10.80
12.57
14.34
16.03
17.72
26 x 75
2.12
3.97
5.77
7.58
9.38
11.54
13.35
15.16
16.96
18.76
28 x 75
2.16
4.11
6.15
8.08
10.06
12.30
14.23
16.16
18.14
20.12
28 x 79
2.33
4.23
6.28
8.28
10.30
12.56
14.56
16.56
18.58
20.60
30 x 36
1.30
2.60
3.82
5.15
6.28
7.64
8.97
10.30
11.43
12.56
30 x 67
2.07
3.91
5.69
7.63
9.39
11.38
13.32
15.26
17.02
18.78
30 x 75
2.23
4.23
6.23
8.24
10.19
12.46
14.47
16.48
18.43
20.38
30 x 79
2.37
4.46
6.51
8.70
10.74
13.02
15.21
17.40
19.44
21.48
NOTES: 1. All amperages are design amperages subject to the following tolerances: heated glass +/- 8%.
2. Although the amperages are calculated at 120 volts, all doors are designed to operate without
sweating when used within the application parameters with a voltage range of +/- 10%.
3. Design parameters do not make allowances for factors such as air leaks or unusual air flow
patterns within cases; therefore, some sweating may occur when upper limits of temperature or
humidity are encountered.
4. See following chart for calculating additional Light Amperage for “ELS” Electronic Lighting:
