Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 87 of 95
“ELS” Lighting System 120 Volt Light Amperage (per frame section)
No. Doors:
1
2
3
4
5
No. “ELS” Lights:
2
3
4
5
6
LAMPS LENGTH
TOTAL AMPS
48”
0.92
1.45
1.84
2.37
2.76
60”
1.30
2.02
2.60
3.32
3.90
72”
1.31
2.07
2.62
3.38
3.93
79. Heat Load in BTU/Hr for Model 101 Normal Temp Glass, Door Rail,
Frame Heaters and “ELS” Electronic Lighting System
(Per Door, with Doors Closed @ 75°F Store Ambient)
MODEL 101 “ELS” NORMAL TEMPERATURE
(2-PANE NON-HEATED GLASS – CASE TEMP 38°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
336
572
808
1044
1281
24 x 67
524
908
1291
1674
2058
24 x 75
589
1018
1448
1877
2306
26 x 67
542
942
1342
1743
2143
26 x 75
608
1056
1505
1953
2401
28 x 75
627
1094
1562
2029
2496
28 x 79
643
1125
1608
2091
2574
30 x 36
365
630
896
1161
1426
30 x 67
576
1010
1445
1879
2314
30 x 75
646
1132
1619
2105
2591
30 x 79
663
1165
1668
2171
2674
MODEL 101 NORMAL TEMPERATURE
(3-PANE NON-HEATED GLASS OR 2-PANE REFL. NHG – CASE TEMP 33°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
349
598
847
1097
1346
24 x 67
541
940
1340
1740
2139
24 x 75
606
1053
1499
1946
2392
26 x 67
557
973
1389
1805
2221
26 x 75
624
1089
1553
2018
2482
28 x 75
642
1125
1607
2090
2572
28 x 79
658
1156
1655
2153
2651
30 x 36
378
656
934
1212
1490
30 x 67
590
1038
1487
1935
2384
30 x 75
660
1161
1661
2162
2662
30 x 79
677
1194
1711
2228
2746
