Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 90 of 95
82. Heat Load in BTU/Hr for Model 2100 Low Temp Glass, Door Rail,
Frame Heaters and “ELS” Electronic Lighting System
(Per Door, with Doors Closed @ 75°F Store Ambient)
MODEL 2100 “ELS” LOW TEMPERATURE – HEATED GLASS
(3-PANE REFLECTIVE HEATED GLASS – CASE TEMP -10°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
495
887
1278
1668
2059
24 x 67
780
1410
2040
2669
3299
24 x 75
874
1577
2280
2983
3686
26 x 67
815
1479
2143
2807
3472
26 x 75
908
1646
2384
3122
3860
28 x 75
947
1724
2501
3277
4054
28 x 79
973
1776
2578
3381
4184
30 x 36
557
1008
1459
1910
2361
30 x 67
879
1607
2335
3063
3791
30 x 75
979
1787
2596
3404
4212
30 x 79
1009
1848
2687
3526
4365
NOTE: Add 10-20% to above values depending on door opening frequency.
83. Electrical Information for Model 2100 Normal Temp Doors,
Frames & “ELS” Electronic Lighting System
Heater Amperages @ 120 Volts
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE: Normal temp doors without heaters, 3-Pane Non-Heated Glass
APPLICATION: Case Temperature 38°
F, Humidity 70% @ 75
°
F ambient.
24 x 36
0.27
0.54
0.81
1.08
1.35
1.62
1.89
2.16
2.43
2.70
24 x 67
0.42
0.84
1.26
1.68
2.10
2.52
2.94
3.36
3.78
4.20
24 x 75
0.46
0.92
1.37
1.83
2.29
2.74
3.20
3.66
4.12
4.58
26 x 67
0.43
0.86
1.28
1.71
2.14
2.56
2.99
3.42
3.85
4.28
26 x 75
0.47
0.95
1.42
1.89
2.37
2.84
3.31
3.78
4.26
4.74
28 x 75
0.50
0.99
1.49
1.99
2.48
2.98
3.48
3.98
4.47
4.96
28 x 79
0.52
1.03
1.55
2.06
2.58
3.10
3.61
4.12
4.64
5.16
30 x 36
0.31
0.62
0.94
1.25
1.56
1.88
2.19
2.50
2.81
3.13
30 x 67
0.46
0.93
1.39
1.86
2.32
2.78
3.25
3.72
4.18
4.64
30 x 75
0.49
0.98
1.47
1.96
2.45
2.94
3.43
3.92
4.41
4.90
30 x 79
0.51
1.02
1.52
2.03
2.54
3.04
3.55
4.06
4.57
5.08
