ANthony 101 - Heat Load in BTU;Hr for Model 2100 Low Temp Glass, Door Rail, Frame Heaters and “ELS” Electronic Lighting System

Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 84 of 95
11
12
13
14
15
16
17
18
19
20
24 x 36
11.79
12.78
13.93
14.92
15.99
17.04
18.11
19.26
20.25
21.32
24 x 67
18.16
19.77
21.40
23.01
24.63
26.36
27.98
29.61
31.22
32.84
24 x 75
19.91
21.72
23.49
25.30
27.09
28.96
30.75
32.52
34.33
36.12
26 x 67
19.90
21.69
23.30
25.09
26.79
28.92
30.62
32.23
34.02
35.72
26 x 75
21.33
23.16
25.23
27.06
29.01
30.88
32.83
34.90
36.73
38.68
28 x 75
22.52
24.48
26.58
28.54
30.57
32.64
34.67
36.77
38.73
40.76
28 x 79
23.70
25.77
28.02
30.09
32.25
34.36
36.52
38.77
40.84
43.00
30 x 36
14.59
15.96
16.93
18.30
19.47
21.28
22.45
23.42
24.79
25.96
30 x 67
21.36
23.34
24.94
26.92
28.71
31.12
32.91
34.51
36.49
38.28
30 x 75
23.18
25.23
27.18
29.23
31.23
33.64
35.64
37.59
39.64
41.64
30 x 79
24.46
26.70
28.62
30.86
32.94
35.60
37.68
39.60
41.84
43.92
78. Electrical Information for Model 101 Normal Temp Doors,
Frames & “ELS” Electronic Lighting System
Heater Amperages @ 120 Volts
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE: Normal temp doors with heaters, 2-Pane Non-Heated Glass
APPLICATION: Case Temperature 38°
F, Humidity 65% or less, @ 75
°
F ambient.
24 x 36
0.27
0.55
0.82
1.09
1.36
1.64
1.91
2.18
2.45
2.72
24 x 67
0.43
0.86
1.30
1.73
2.16
2.60
3.03
3.46
3.89
4.32
24 x 75
0.46
0.92
1.39
1.85
2.31
2.78
3.24
3.70
4.16
4.62
26 x 67
0.44
0.87
1.31
1.74
2.18
2.62
3.05
3.48
3.92
4.36
26 x 75
0.47
0.93
1.40
1.87
2.34
2.80
3.27
3.74
4.21
4.68
28 x 75
0.50
0.99
1.49
1.99
2.48
2.98
3.48
3.98
4.47
4.96
28 x 79
0.49
0.97
1.46
1.95
2.43
2.92
3.41
3.90
4.38
4.86
30 x 36
0.31
0.62
0.92
1.23
1.54
1.84
2.15
2.46
2.77
3.08
30 x 67
0.47
0.94
1.40
1.87
2.34
2.80
3.27
3.74
4.21
4.68
30 x 75
0.49
0.98
1.47
1.96
2.45
2.94
3.43
3.92
4.41
4.90
30 x 79
0.53
1.05
1.58
2.10
2.63
3.16
3.68
4.20
4.73
5.26
