ANthony 101 - Heat Load in BTU;Hr for Model 2100 Normal Temp Glass, Door Rail, Frame Heaters and “ELS” Electronic Lighting System

Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 82 of 95
MODEL 2100 NORMAL TEMPERATURE
(3-PANE NON-HEATED GLASS – CASE TEMP 38°F) – LOW ENERGY PRODUCT
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
544
862
1181
1500
1819
24 x 67
617
1010
1402
1795
2187
24 x 75
636
1048
1459
1871
2282
26 x 67
629
1034
1438
1843
2247
26 x 75
650
1075
1499
1924
2349
30 x 36
564
903
1242
1581
1921
30 x 67
654
1082
1511
1939
2368
30 x 75
677
1128
1580
2032
2483
NOTE: Add 10-20% to above values depending on door opening frequency.
76. Heat Load in BTU/Hr for Model 101 Low Temp Glass, Door Rail,
Frame Heaters and “ELS” Electronic Lighting System
(Per Door, with Doors Closed @ 75°F Store Ambient)
MODEL 101 “ELS” LOW TEMPERATURE
(3-PANE HEATED REFLECTIVE GLASS – CASE TEMP -10°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
487
867
1248
1628
2009
24 x 67
762
1373
1984
2595
3206
24 x 75
795
1532
2213
2894
3575
26 x 67
886
1439
2083
2727
3371
26 x 75
886
1601
2317
3032
3748
28 x 75
923
1675
2428
3181
3933
28 x 79
948
1725
2502
3279
4056
30 x 36
545
983
1422
1860
2299
30 x 67
855
1560
2265
2970
3675
30 x 75
953
1735
2518
3300
4083
30 x 79
982
1794
2605
3417
4229
NOTE:
Add 10-20% to above values depending on door opening frequency.
