ANthony 101 - Four-Post Stabilizer Bar Installation; Four-Post Shelf System Installation

Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 44 of 95
44. Four-Post Stabilizer Bar Installation
1. The four-post stabilizer is designed to help support the posts during installation and
stabilize the system while in use.
2. Insert the forked end of stabilizer bar into the elongated holes in post.
3. Install the post stabilizers on the top and bottom of all posts, front to rear, before
installing shelves.
45. Four-Post Shelf System Installation
1. Attach post to inside frame by inserting post key into frame retaining bracket.
.
2. Before installing shelves, adjust all front posts to equal heights with leg leveling bolts at
bottom of posts.
