Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 91 of 95
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE:
Normal temp doors without heaters, 3-Pane Non-Heated Glass
APPLICATION:
Case Temperature 38°F, Humidity 65% @ 75°F ambient (Low Energy Product)
24 x 36
0.17
0.33
0.52
0.69
0.87
1.04
1.21
1.38
1.56
1.74
24 x 67
0.27
0.53
0.80
1.06
1.33
1.60
1.86
2.12
2.39
2.66
24 x 75
0.29
0.59
0.88
1.17
1.47
1.76
2.05
2.34
2.64
2.94
26 x 67
0.28
0.55
0.83
1.10
1.38
1.66
1.93
2.20
2.48
2.76
26 x 75
0.28
0,57
0.85
1.14
1.42
1.70
1.99
2.28
2.56
2.84
30 x 36
0.20
0.38
0.60
0.79
0.99
1.20
1.39
1.58
1.78
1.99
30 x 67
0.30
0.59
0.89
1.19
1.49
1.78
2.08
2.38
2.68
2.97
30 x 75
0.31
0.62
0.94
1.25
1.56
1.88
2.19
2.50
2.81
3.13
NOTES: 1. All amperages are design amperages subject to the following tolerances: non-heated glass +/- 5%.
2. Although the amperages are calculated at 120 volts, all doors are designed to operate without
sweating when used within the application parameters with a voltage range of +/- 10%.
3. Design parameters do not make allowances for factors such as air leaks or unusual air flow
patterns within cases; therefore, some sweating may occur when upper limits of temperature or
humidity are encountered.
4. See following chart for calculating additional Light Amperage for “ELS” Electronic Lighting:
“ELS” Lighting System 120 Volt Light Amperage (per frame section)
No. Doors:
1
2
3
4
5
No. “ELS” Lights:
2
3
4
5
6
LAMPS LENGTH
TOTAL AMPS
48”
0.92
1.45
1.84
2.37
2.76
60”
1.30
2.02
2.60
3.32
3.90
72”
1.31
2.07
2.62
3.38
3.93
11
12
13
14
15
16
17
18
19
20
24 x 36
2.97 3.24 3.51 3.78 4.05 4.32 4.59 4.86 5.13 5.40
24 x 67
4.62
5.04
5.46
5.88
6.30
6.72
7.14
7.56
7.98
8.40
24 x 75
5.03
5.49
5.95
6.41
6.87
7.32
7.78
8.24
8.70
9.16
26 x 67
4.70 5.13 5.56 5.99 6.42 6.84 7.27 7.70 8.13 8.56
26 x 75
5.20
5.67
6.15
6.63
7.11
7.56
8.04
8.52
9.00
9.48
28 x 75
5.47
5.97
6.45
6.95
7.44
7.96
8.45
8.93
9.43
9.92
28 x 79
5.67 6.18 6.71 7.22 7.74 8.24 8.76 9.29 9.80 10.32
30 x 36
3.44
3.75
4.06
4.37
4.69
5.00
5.31
5.62
5.93
6.25
30 x 67
5.11
5.58
6.04
6.50
6.97
7.44
7.90
8.36
8.82
9.30
30 x 75
5.39 5.88 6.37 6.86 7.35 7.84 8.33 8.82 9.31 9.80
30 x 79
5.58
6.09
6.60
7.11
7.62
8.12
8.63
9.14
9.65
10.16
