5.2. DIN Rail Mounng
IMPORTANT
The equipment must be electrically grounded through the DIN rail for EMC compliance. Make sure
that the equipment is correctly mounted on the rail and that the rail is properly grounded.
Figure 4. Aach the Communicator on the DIN rail
To aach the Communicator on the DIN rail:
1. Insert the upper end of the DIN rail clip into the DIN rail.
2. Push the boom of the DIN rail clip into the DIN rail.
DIN Rail Mounng Anybus
®
Communicator
- PROFINET IO-Device to EtherNet/IP Adapter
