7. PLC Conguraon
7.1. Export Product GSDML File
Opon for PROFINET IO-Device.
Opon if the PLC program requires a product le, GSDML (Generic Staon Descripon Markup Language) le,
describing how the Communicator can be used on the high level network.
Figure 34. Files & rmware page, PROFINET GSDML le
You nd the PROFINET GSDML le on the Communicator built-in web interface PROFINET page, Files &
rmware page and on the Support page.
To export the GSDML le:
Click GSDML le.
The GSDML le is downloaded to your PC.
PLC Conguraon Anybus
®
Communicator
- PROFINET IO-Device to EtherNet/IP Adapter
SCM-1202-195 Version 1.0 Page 37 of 56
