Anybus Communicator User Manual

6.4. Communicator Built-In Web Interface Overview
Use the Communicator built-in web interface to congure, maintain and troubleshoot the Communicator.
Figure 13. The Communicator built-in web interface Home page
Menu item Descripon
Home View the Communicator, network and node status.
Apply Aer conguraon changes are made and veried, press Apply to make the sengs take eect.
PROFINET Congure the network sengs for the PROFINET network.
EtherNet/IP Congure the network sengs for the EtherNet/IP network.
I/O conguraon Congure input and output data sizes and endian conversion.
Files & rmware Save sengs in a conguraon les, upload conguraon les and upgrade rmware.
Diagnoscs Monitor and troubleshoot the Communicator.
Support Contains Communicator product informaon, Anybus contact informaon, link to Anybus support website, and
product le for download.
Here you can generate a support package with product informaon, to send to your Anybus support technician.
Anybus
®
Communicator
™
- PROFINET IO-Device to EtherNet/IP Adapter Communicator Built-In Web Interface Overview
Page 22 of 56 SCM-1202-195 Version 1.0

Anybus Communicator Specifications

General

Protocols Supported	PROFINET, EtherNet/IP, Modbus TCP
Serial Interfaces	RS-232, RS-485
Ethernet Protocols	Modbus TCP, EtherNet/IP, PROFINET
CAN Protocols	CANopen
Operating Temperature	-25°C to +70°C
Storage Temperature	-40°C to +85°C
Humidity	5% to 95% non-condensing
Power Supply	24V DC
Enclosure	Plastic
Protection Class	IP20
