To Congure IP Sengs Manually
Figure 15. PROFINET IP Sengs, DCHP disabled
1. Ensure that the DHCP enabled checkbox is deselected.
2. Congure the IP sengs.
Seng Descripon
IP address The PROFINET network IP address in IPv4 dot-decimal notaon
Subnet mask The PROFINET network Subnet mask in IPv4 dot-decimal notaon.
Gateway address The PROFINET network Gateway address in IPv4 dot-decimal notaon.
If there is no gateway available, set the Gateway address to: 0.0.0.0
Primary DNS server The PROFINET network Primary DNS in IPv4 dot-decimal notaon.
Secondary DNS server The PROFINET network Secondary DNS in IPv4 dot-decimal notaon.
DHCP O
Hostname You can label the Communicator. Maximum length is 64 characters. No symbol characters, punctuaon
characters, or whitespace are permied. Write the Hostname as one single word.
If you change a value and click Refresh, the value is reset to the last applied value.
Anybus
®
Communicator
™
- PROFINET IO-Device to EtherNet/IP Adapter PROFINET Sengs
Page 24 of 56 SCM-1202-195 Version 1.0

Anybus Communicator Specifications

General

Protocols Supported	PROFINET, EtherNet/IP, Modbus TCP
Serial Interfaces	RS-232, RS-485
Ethernet Protocols	Modbus TCP, EtherNet/IP, PROFINET
CAN Protocols	CANopen
Operating Temperature	-25°C to +70°C
Storage Temperature	-40°C to +85°C
Humidity	5% to 95% non-condensing
Power Supply	24V DC
Enclosure	Plastic
Protection Class	IP20
