The SAFE button protects the Small Fader from being muted when the Solo-In-Place function
is active and another channel is soloed
Protects from global changes to channel routing (input and compressor)
Illuminates when engaged
Ø (Phase Reverse): Inserts a polarity inverter into the Small Fader path
Illuminates when engaged
PAN: This is the pan pot control for the Small Fader path
-2.5dB pan law
Left/Right panning to stereo Program Buses A, B, and C
Odd/Even panning to Multitrack Buses 1-24
The SM PAN button in the 624 Bus Assignment module must be engaged for the pan-pot to
work
ALT: Routes Alternate Line Input to the Small Fader path input
The upper 200 slot Preamp Output is the default input for the Small Fader path
Will engage on all channels when the SM ALT LINE button is engaged in the Master Section
Illuminates when engaged
INS (Insert): Activates the Small Fader path Insert Return
Insert Send is fed from the output of the 500 Series EQ slot
Insert Send is always active
Insert Return is located pre the Small Fader
The Insert Return is active only when the INS button is engaged
Controlled by automation
Illuminates when engaged
SMALL FADER: Level control for the Small Fader path
45mm resistive fader
+10dB of gain
-∞dB of attenuation
Unity gain when set to 0dB
Global 0dB Fader Bypass (in Master Section)
Not automatable
NOTE: A 0dB Small Fader bypass can be applied to all channels by engaging the 0dB SM button
in the Master Section. This feature provides is useful an additional Small Fader gain stage
is not needed or when using DAW automation.
SOLO: Activates the selected solo function for the Small Fader path. The following solo functions may
be selected via the Master Section:
Pre-fader Listen (PFL): Non-destructive, mono
Pre-EQ & Insert Listen (PFL2): Non-destructive, mono
After Fader Listen (AFL): Non-destructive, panned
Solo-In-Place (SIP): Destructive, panned, post-fader
Will disengage when the SOLO CLR button is engaged in the Master Section
Illuminates in yellow when engaged
NOTE: AFL is the default solo mode.
MUTE: Cuts the Small Fader path signal
The MUTE button is the on/off switch for the Small Fader audio path
Can be engaged by Solo-In-Place solos
Controlled by automation
Illuminates in red when engaged
