Large Fader
AUTOMATION MUTE: (Channel Mute) Cuts the Large Fader audio output
The MUTE button is the on/off switch for the Large Fader
Activates the 968 MUTE button
Not activated by the 968 MUTE button
Controlled by automation
• Illuminates in red when engaged
LARGE FADER: Controls the output level of the Large Fader audio path
Full-size 100mm resistive fader
+10dB of gain
-∞dB of attenuation
Unity gain when set to 0dB
0dB fader bypass (in via automation system)
Controlled by automation
NOTE: A 0dB Large Fader bypass can be applied via the automation system.
This feature is useful if an additional Large Fader gain stage is not needed or when
using DAW automation/worksurface control.
